1064nm Wave 10W 20W 30W Fiber Laser Making Machine For Metal And Plastic

Name: 1064nm Wave 10W 20W 30W Fiber Laser Making Machine For Metal And Plastic
Brand: YUSH
Price: 4500 USD

Brand Name : YUSH

Model Number : YS-FY-20W

Certification : CE

Place of Origin : China

MOQ : 1

Price : $4500-6800 pice

Payment Terms : T/T

Supply Ability : 100 piece per month

Delivery Time : 15 work days

Packaging Details : wooden case and vacuum packaging

Model : YS-FY-20W

Laser power： : 20W

Length of laser wave： : 1064nm

Marking area： : 50*50MM,100*100MM,150*150MM,200*200(Options）

Marking speed： : ≤ 7000mm/s

positionaI accuracy： : ±0.003mm

Contact Now

1064nm Wave 10W 20W 30W Fiber Laser Making Machine For Metal And Plastic

Model:	YS-FY-20W
Laser power:	20W
Length of laser wave:	1064nm
Marking area:	5050MM,100100MM,150150MM,200200(Options)
Marking depth:	≤ 0.5mm/≤ 1.2mm
Marking speed:	≤ 7000mm/s
Min line width:	90um
optical quality M2	<1.8
power stability (24H)	<±1%rms
Min character:	0.1mm
Pulse frequency	20-200KHz
positionaI accuracy:	±0.003mm
safety index	Ⅳ
type of cooling:	forced air
Laser safety rating	1P54
operating temperature:	15℃--35℃
ystem operating environment:	WindowsXP/Windows2000
average power consumption:	≤ 0.5kw
supply voltage:	220V 20A50HZ

Work environment requirements

The ambient temperature is required to be between 5 and 40 ° C and air conditioning is required.

Humidity requirements are 40%-80%. No condensation, a dehumidifier should be installed.

Power supply grid requirements: 220V; 50Hz

Power supply grid fluctuation: ± 5%, the grid ground wire meets international requirements. In areas with a voltage amplitude of 5% or more, an automatic voltage regulator and a current stabilizing device should be installed.

There should be no strong electromagnetic interference near the installation equipment. Avoid radio transmitting stations (or relay stations) around the installation site.

Ground amplitude: less than 50um; vibration acceleration: less than 0.05g. Avoid a large number of machine tools such as stamping in the vicinity.

The space requirements of the equipment should be smoke-free and dust-free, and avoid the dusty working environment such as metal polishing and grinding.

Air pressure: 86-106kpa. Some environments should be equipped with anti-static flooring, enhanced shielding, etc.
